DETAILS
| Frame Material: | AL 7003 aircraft |
|---|---|
| Frame Manufacturing Process: | Extruded and CNC machining |
| Frame Wheel Base (Inch / MM): | 13.2" / 335mm |
| Max. Wheel Size: | 125mm (3 wheels) or 110mm (4 wheels) |
| Frame Axles: | Double axle, steel, 8mm, Torx T25, 1mm rocker, L=33mm / single axle AL 7075, 8mm, Torx T25, L=35mm |
| Adjustable Side to Side: | true |
| Adjustable Front to Back: | true |
| Included Accesssories: | AL spacer, 4 washers 1mm thick, 6 screws 10mm, 6 screws 12mm, 6 screws 15mm, 1 IQON tool Torx T25 |
| Wheel Compound: | Ultra Reactive Polyurethane |
|---|---|
| Wheel Diameter: | 125mm |
| Wheel Width: | 24mm |
| Wheel Hardness: | 85A |
| Wheel Profile: | Round |
| Wheel Core: | 5 Star |
| Wheel Bearing Standard: | 608 / Decode |
| Wheel Spacer: | AL floating spacer, 8mm |
| Bearing Brand: | Iqon |
|---|---|
| Bearing Rating: | ABEC 9 |
| Bearing Standard: | 606 standad / Decode standard |
| Bearing Shield: | RZ, single sided rubber coated steel |
| Bearing Lubrication: | Light grease |
